Description
|
The new NOVAPRO HD is an advanced high performance LED display controller, video processor, and configuration device that supports multiple signal formats. Compatible with all ADJ Video Panels. The new NOVAPRO HD is an advanced high performance LED display controller, video processor, and configuration device that supports multiple signal formats including DP / HDMI / VGA / DVI / CVBS / 3G-SDI, up to 1080p @60Hz input resolution, 165MHz pixel clock and 4G-Bit output bandwidths. NOVAPRO HD also includes DMX512 and GenLock interfaces, Ethernet ports for communication through standard TC/IP and USB control for cascading with additionalNOVAPRO HD’s. NOVAPRO HD is compatible with all of ADJ’s current video products. |
SpecificationsFEATURES: No Computer or External Scaler Needed (standard rectangular layouts only) Up to 1080p @60Hz Input Resolution 165Mhz Pixel Clock / 4G-Bit Output Bandwidth Multiple Video Signal Format Support Cascade Multiple Units Together Rack Mountable Aluminum Enclosure (screws not included)
CONTROL / CONNECTIONS: (1) Input and (4) Output RJ45 EtherCON Ports USB, 5pin DMX, and GenLock In/Out Ports Audio Input: 1/8 inch connector Video Input: DP / HDMI / VGA / DVI / CVBS / 3G-SDI Locking IEC Power Input
SIZE / WEIGHT: Length: 19.0” (483mm) Width: 15.3” (389mm) Height: 3.5” (88.2mm) Weight: 13.2 lbs. (6.0kg)
ELECTRICAL: AC 85-265V - 50/60Hz - 0.65A Max Power Consumption: 30W |
