Description
BC810-72: Open Beam Speaker |
| An 8 in. driver/transformer/grille assembly with a round enclosure that features clamps to mount to a beam or girder. |
|
PERFORMANCE Background music and paging ASSEMBLY INCLUDES • Driver (No. 810): 8 in. 15W dual cone with power rating of 15 watts RMS and 10 oz. ceramic magnet. • Transformer (No. TLM- 572): Wired dual voltage 70/25V transformer with taps at .25, .5, 1, 2 and 5W. • Grille (No. WB-8): Round screw-mount steel grille, 12.875 in. diameter. White powder epoxy finish. White screws. • Enclosure (No. 8XD4): Includes two beam clamps mounted on top. White powder epoxy finish. Externally accessible speaker leads exit through a metal strain-relief clamp for fast installation. COMPLIANCE & CERTIFICATION • Certified U.S. steel enclosure, grille • Made in the U.S.A. with global components A&E SPECIFICATIONS The speaker shall be Lowell Model No. BC-810-72, which shall include an 8" 15W dual cone driver, dual voltage transformer, and steel screw-mount grille mounted to a conically shaped backbox with externally accessible, strain-relieved leads and top-mounted beam clamps. The driver shall have a frequency response of 54Hz-11.6kHz (+6dB), 50Hz- 20kHz (+6.6dB) and sensitivity of 97.9dB. The factory wired transformer shall be dual voltage 70/25V with power taps at .25, .5, 1, 2, and 5 watts. The speaker assembly shall be finished in white powder epoxy. |
