AD-S112SW

-S112SW AcousticDesign Subwoofer

Features

12-inch weather treated woofer
TFR™ (Turbulent Flow Reduction) port provides optimal resonant tuning and high velocity air flow
Maximum peak SPL 121 dB
Suggested filter points: 32 Hz high-pass, 24 dB/octave Butterworth; 100 Hz low-pass, 24 dB/octave Butterworth
Included YMS12 yoke mount maximizes boundary plane coupling while reducing vibration transmission
Optional M10 Kit-C for additional installation versatility
Lightweight ABS enclosures offer long-term durability and lasting good looks
Sealed input panel cover and powder coated aluminum grilles for added weather resistance
Meets IEC60529 IP-54 for dust and splash resistance
Available in black (RAL 9011)
Complete EASE, CF2, CAD, and BIM information available online

System Details	AD-S112sw
Effective frequency range1	30 - 135 Hz
Rated noise power / voltage2	300 watts / 50 volts (rms)
Broadband Sensitivity3	90 dB SPL
Maximum continuous SPL4	115 dB
Maximum peak SPL4	121 dB
Rated impedance	8 ohms
Recommended amplifier power (loudspeaker "program" power)	600 watts
Transformer taps	n/a
HF transducer	-
LF transducer	12-inch weather resistant paper cone woofer, 2.5-inch / 64mm voice coil
Input connector type	Euroblock connector with parallel output terminals
Enclosure material	Painted ABS polymer
Grille material	Powder coated aluminum
Yoke material	Powder coated galvanized steel (included)
Enclosure Details
Ingress protection	IP-54
Operating environment	Designed for indoor and outdoor use
Testing	The AD Series loudspeakers qualified for outdoor use using the following tests: Salt fog: MIL-STD-810G Method 509.5 for 100 hrs. Humidity: MIL-STD-810G Method 507.5, Natural cycle B2, cyclic high RH for 7 days High and low temperature: tested to QSC internal standards between -20° & 50° C
Product Dimensions (HWD) inches	23.4 x 13.9 x 12.7
Product Dimensions (HWD) mm	594 x 354 x 323
Net weight	29 lb / 13.2 kg
Shipping weight	43.1 lb / 19.6 kg
Shipping dimensions	27.5-inch x 21.75-inch x 18.5-inch (698 x 552 x 470 mm)
Included accessories	YMS12 yoke mounting system, Euroblock connector, input panel cover
1 Free-field, -10 dB from on-axis sensitivity 2 IEC60268-1 noise signal for 2 hours 3 On-Axis, free-field sensitivity, 2.83V, 1 m 4 Calculated from rated noise voltage and sensitivity

All specifications are subject to change without notice.
