| Configuration |
12-inch 2-way multipurpose |
Transducers
Low-frequency
Mid-frequency
High-frequency |
12-inch cone transducer
-
1.75-inch diaphragm compression driver |
| Frequency Response (-6 dB) |
53 Hz to 18 kHz |
| Frequency Range (-10 dB) |
50 Hz to 20 kHz |
| Nominal Coverage (-6 dB) |
75° axisymmetric |
| Maximum SPL1 |
131 dB peak |
| Amplifier |
| Power Output2 |
1000 W Class D (500 W LF + 500 W HF) continuous
2000 W peak |
| Input Impedance |
Channel A XLR / ¼?????:
| Mic gain setting |
Balanced |
Unbalanced |
| 0 dB |
38 k? |
19 k? |
| +12 dB |
10 k? |
5 k? |
| +24 dB |
2.66 k? |
1.33 k? |
| +36 dB |
660? |
330? |
Channel B XLR / ¼?????: 38 k? balanced / 19 k? unbalanced
Channel B RCA: 10 k? |
| Controls |
Power, Gain A, Gain B, Channel A Input Gain (0 dB / 12 dB / 24 dB / 36 dB), LF Mode (Ext Sub/Norm/DEEP™), HF Mode (Flat/Vocal Boost), Front LED (On/Off/Limit) |
| Indicators |
Power, Signal A, Signal B, Standby, Limit, Mic (24 dB and 36 dB settings) |
| Connectors |
Balanced female XLR/¼????? line/mic level input, Balanced female XLR/¼????? line level input, Dual Balanced male XLR full range line level out , Balanced male XLR "mix" out, Stereo RCA line level input, Remote gain control, Locking IEC power connector |
| Cooling |
On demand, 50 mm variable speed fan |
| Amplifier Protection |
Thermal limiting, output overcurrent, overtemperature muting, GuardRail™ |
| Transducer Protection |
Thermal limiting, excursion limiting |
| AC Power Input |
Universal power supply 100–240 VAC, 50 to 60 Hz |
AC Power Consumption
(1/8 Power) |
100 VAC, 2.3 A
120 VAC, 2.01 A
230 VAC, 1.13 A |
| Enclosure |
| Material |
15 mm painted birch plywood |
| Finish |
Black textured paint |
| Grille |
Black powder coated 16 gauge steel |
| Dimensions (HWD) inches |
26 x 15 x 15.4 |
| Dimensions (HWD) mm |
660 × 381 × 391 |
| Net Weight |
49 lb / 22.2 kg |
| Available Accessories |
KW122 suspension kit, KW122 cover, KW M10 kit |
